UT216C Digital Clamp Meters
Alternate Current 60A/600A ± (2.5%+5)
Direct Current 60A/600A ± (2.5%+5)
Alternate Voltage 6V/60V/600V/750V ±(1.2%+5)
Direct Voltage 600mV/6V/60V/600V/1000V ±(0.8%+1)
Resistance 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ ±(1%+2)
Capacitance 60nF/600nF/6μF/60μF/600μF/6mF/60mF ±(4%+5)
Frequency 10Hz ~ 1MHz ±(0.1%+4)
Temperature -40°C ~ 1000°C ±(2%+10)*
FUNCTIONS
Display Count 6000
Auto Range
Jaw Capacity 30mm
True RMS
Diode Test
NCV
VCF
Data hold
Zero/Rel/max/min Mode
Inrush Current
Bargraf 61
Display Backlight
LED flashlight
Auto Power Off
Continuity Buzzer
Low Battery Indication
Input Protection
Input Impedance DC 10MΩ+
GENERAL CHARACTERISTICS
Power 3x 1.5V AAA
Size 220x75x40mm
LCD Size 38x24mm
Weight 231.7g
